NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
genuine image
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
Our high torque stepper motor is a Nema23 (57x57mm), all-in-one integrated CAN interface smart servo step motor that comes with an encoder, motor driver and motion controller, in an aluminum alloy case.
NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA)
Item #: 148012512

NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN

Item #: 148012512

€ 173

Price Details

Excluding Shipping & Custom charges ( Shipping and custom charges will be calculated on checkout )

*All items will import from US

0 ratings Write a review
In stock
us Imported from USA store

QTY:

Only 16 items left in stock.
Order now and get it around Saturday, June 27
Secured transactionsecured transaction

Ubuy works hard to protect your security and privacy. Our advanced payment security system ensures confidentiality by encrypting your information during transmission using AES (Advanced Encryption Standards) and SSL (Secure Socket Layer) protocols. Your payment details are 100% secure as we do not share your payment details with third party sellers.

Our Top Logistics Partners
  • fedex
  • dhl
Our high torque stepper motor is a Nema23 (57x57mm), all-in-one integrated CAN interface smart servo step motor that comes with an encoder, motor driver and motion controller, in an aluminum alloy case.
Show More
Show More
U-Care Warranty:
None
Select a Plan
fast shipping

Fast
Shipping

free return

Free
Return*

secure packaging

Secure Packaging

100% original products

100% Original Products

pci-dss

PCI DSS Compliance

iso certified

ISO 27001 Certified

paypal payment
visa payment
mastercard payment
Note: Step Down Voltage Transformer required for using electronics products of US store (110-120). Recommended power converters Buy Now.

What Stands Out

Integrated Encoder
This motor features a built-in multi-turn absolute encoder, ensuring precise position feedback and eliminating errors commonly seen in traditional stepper motors for enhanced accuracy.
Closed-Loop Control
The closed-loop servo motion controller optimizes performance by adjusting power according to load conditions, preventing overheating and ensuring consistent torque without losing steps.
CAN Bus Support
Supports CAN bus communication, simplifying integration into complex systems and offering flexibility with multi-device networking for efficient and streamlined control in advanced applications.

Product Details

Shop NEMA 23 Integrated Servo Stepper Motor with Built-in Multi-Turn Absolute Encoder,Closed-Loop Servo Motion Controller and Driver,CAN Bus,2000RPM,Max1.26Nm,3.5A,24-48VDC(UIM5756CA) online at a best price in Malta. B0DK4LRC2H
  • 【MULTI-TURN ABSOLUTE ENCODER】 Our smart motor integrates a NEMA 23 Absolute Multi-Turn Encoder with 17-bit single-turn and 32-bit multi-turn resolution. Featuring Power-Off Memory technology, it maintains exact positioning after shutdown without requiring re-zeroing, saving valuable time while boosting operational efficiency.
  • 【EXCELLENT DESIGN】 The motor features CAN interface with superior anti-interference capability, delivering reliable performance through digital outputs for stable operation in harsh environments. Its closed-loop motion system ensures high positioning accuracy and fast response, achieving speeds up to 2000 RPM. Multiple control functions include speed control, position control, backlash compensation, and stall detection.
  • 【POWERFUL TECHNICAL SUPPORT】 This NEMA 23 stepper motor incorporates a robust DSP core with fault tolerance and fail-safe user interface, complete with free debug/control software plus full SDK support including libraries, DLLs, and example codes in C++ and C#.
  • 【PERFECT REPLACEMENT】 Delivering 1.26 N.m holding torque with 1-128 microstepping resolution, this compact motor operates on 24-48 VDC with adjustable 1-2.8A current. Its vibration-free and low noise operation makes it an exceptional alternative to traditional AC/DC servo motors.
  • 【VERSATILE APPLICATIONS】 Ideal for high-precision, high-reliability applications including industrial robotics (joint positioning), CNC machines, and automated warehousing, among others. Using the CANBUS protocol, multiple motors can communicate simultaneously to achieve complex motion control.
Brand NameUIROBOT
Model NameUIM5756CA
ModelUIM5756CA
ManufacturerUIROBOT
Included ComponentsUIM4247CA Smart Motor
Speed2000 RPM
Voltage48 Volts (DC)
Material TypeAluminum, Metal
BrandUIROBOT
MaterialAluminum, Metal
Item Weight3.5 lbs (1.59 kg)

Who Should Buy?

Suitable For
  • Robotics Enthusiasts

    Ideal for hobbyists building robots, offering precise control and torque for various robotic applications.

  • Industrial Automation

    Suitable for factories requiring reliable and efficient motion control in automated systems and machinery.

  • CNC Machinists

    Perfect for CNC machine operations where high efficiency and accuracy in motion control are paramount.

Not Suitable For
  • Basic Projects

    Not suitable for simple projects requiring low torque and basic stepper motors with fewer complexities.

  • Lightweight Applications

    Users needing minimal power and low-weight motors may find this product more powerful than necessary.

  • Cost-Sensitive Users

    Individuals or businesses with strict budget constraints may find this integrated motor comparatively expensive.

Product Description

Have any Query? Chat with us

Customer Questions & Answers

  • Question: What is a Nema 23 stepper motor and its key specifications?

    Answer: A Nema 23 stepper motor is a high-performance motor commonly used in automation applications. Key specifications include a 57mm frame size, integrated servo system, and it operates at 2000RPM with a current rating between 0.4A and 4A. This type of motor is ideal for applications that require precise control of angular position and speed, such as CNC machinery and robotics.
  • Question: What are the advantages of using an integrated servo system in stepper motors?

    Answer: An integrated servo system in stepper motors offers several advantages, including enhanced torque, improved efficiency, and smoother motion control. This integration allows for real-time feedback via the encoder, which enhances positional accuracy and operational stability. Users can apply this technology in intricate projects where precision and reliability are paramount.
  • Question: How does an encoder work in a stepper motor configuration?

    Answer: An encoder in a stepper motor setup provides feedback on the motor's position, velocity, and direction. It translates the motor's rotational movement into digital signals that the motion controller can interpret. This feedback mechanism allows for more accurate control and adjustments, making it especially useful in applications like robotics and automated machinery where precision is critical.
  • Question: What types of projects are best suited for a Nema 23 57mm stepper motor?

    Answer: A Nema 23 stepper motor is ideal for various projects including CNC milling machines, 3D printers, and automated assembly lines. Its ability to handle high torque and maintain precise positioning makes it suitable for tasks requiring consistent performance and reliability. If you're working on designs that require detailed movements, this motor can enhance overall functionality.
  • Question: What voltage and current range do I need to operate this stepper motor?

    Answer: This Nema 23 stepper motor operates on a voltage range of 24-36VDC and a current range between 0.4 to 4A. Choosing the right voltage and current is critical to ensure optimal performance and prevent damage. Users should refer to the motor specifications and select a compatible power supply that meets these requirements for effective operation in their applications.
  • Question: Can this motor be controlled using a standard Arduino board?

    Answer: Yes, the Nema 23 stepper motor can be controlled using a standard Arduino board. By integrating a suitable motor driver compatible with the motor's specifications, users can write simple code to command movement. This setup is widely utilized in DIY projects and educational kits where users experiment with robotics or CNC applications.
  • Question: What kind of maintenance is required for a stepper motor with an integrated servo system?

    Answer: Maintenance for a stepper motor with an integrated servo system generally involves keeping connections secure and ensuring that the motor remains clean and free of dust. Periodically checking the power supply and controls is essential for optimal performance. Regular inspection helps prevent performance issues and lengthens the motor's lifespan in various applications.
  • Question: Is it necessary to use a motion controller with this stepper motor?

    Answer: While it’s not strictly necessary, using a motion controller with the Nema 23 stepper motor significantly enhances its performance. The controller interprets commands and manages real-time feedback from the encoder, allowing for more precise motion control. Applications that demand high accuracy and multi-axis movement will highly benefit from a dedicated motion controller.
  • Question: What is the torque capacity of this stepper motor?

    Answer: The torque capacity of the Nema 23 stepper motor varies depending on the specific model, but generally, it delivers sufficient torque for demanding applications. The ability to achieve high torque makes it suitable for reducing stalling and improving the efficiency of processes requiring automated movement. This characteristic is crucial for achieving reliable performance in industrial settings.
  • Question: Where can I buy Nema 23 57mm Stepper Motor, Integrated Servo System Smart Stepper Motor with Encoder, Driver & Motion Controller, 2000RPM 0.4-4A 24-36VDC Torque in Malta?

    Answer: You can purchase the Nema 23 57mm stepper motor along with its integrated servo system directly from Ubuy in Malta. Ubuy offers a wide selection of technical components and comprehensive product details, ensuring that you find the right setup for your needs comfortably.

UIROBOT Motor Drives Editorial Review

No editorial reviews found

Customer Reviews & Ratings

5.0
1 customers ratings
  • 5 Star
    100%
  • 4 Star
    0%
  • 3 Star
    0%
  • 2 Star
    0%
  • 1 Star
    0%

Review this product

Share your thoughts with other customers

Pros

  • High precision and accuracy
  • Easy to install and use
  • Integrated driver saves space
  • Wide voltage range compatibility
  • Fast response with 2000 RPM

Cons

  • Some users may find it slightly heavy.

Related Categories

Industrial 3D Printer Motors
Mini Computers

Product Price History

Important information

  • Limitations : For products shipped internationally, please note that any manufacturer warranty may not be valid; manufacturer service options may not be available; product manuals, instructions, and safety warnings may not be in destination country languages; the products (and accompanying materials) may not be designed in accordance with destination country standards, specifications, and labeling requirements; and the products may not conform to destination country voltage and other electrical standards (requiring use of an adapter or converter if appropriate). The recipient is responsible for assuring that the product can be lawfully imported to the destination country. When ordering from Ubuy or its affiliates, the recipient is the importer of record and must comply with all laws and regulations of the destination country.
  • Not all the products listed on Ubuy are for sale, as Ubuy is a global search engine. Products are subject to export/trade regulations.

€ 173

Order now and get it around Saturday, June 27

QTY:

Only 16 items left in stock.
Secured transactionsecured transaction

Ubuy works hard to protect your security and privacy. Our advanced payment security system ensures confidentiality by encrypting your information during transmission using AES (Advanced Encryption Standards) and SSL (Secure Socket Layer) protocols. Your payment details are 100% secure as we do not share your payment details with third party sellers.

Our Top Logistics Partners
  • fedex
  • dhl
Fastest cross-border delivery

Features & Benefits

  • High torque Nema 23 stepper motor with 1.26 N.m holding torque.
  • All-in-one design includes encoder, motor driver, and motion controller.
  • Fast performance up to 2000 RPM with low noise and vibration.
  • Supports multiple control functions like speed and position control.
  • Robust technical support with free software and complete SDK.
  • Ideal substitute for AC/DC servo motors at low speeds.
